In science, this term, we did 4 experiments to see the effects of heat on particles:
Conduction(melting ice)
The first one was about conduction. Conduction is when thermal energy(heat) cause particles to vibrate vigorously. When the particles vibrate they transfer heat to nearby particles. We put ice cubes on two different surfaces(metal and plastic) to see which one would melt faster. We saw the cube on the metal surface melted faster. We found out this happened because metal was a better conductor so it could transfer heat to the ice cube quick. The plastic surface was slower at transferring heat to the ice so the ice melted much slower.
Convection(heating potassium permanganate)
The next experiment was looking at convection; convection is when warmer areas of a liquid or gas rise up(because they are less dense), and the cooler areas sink down(because they are more dense). We put a small purple crystal – potassium permanganate – in a beaker with water. We heated the beaker and saw purple trails rising up and sinking down(it made a circle). This was a convection current.
Contraction(imploding cans)
The third experiment: contraction. When an area of particles are cooled, the particles contract(come closer together). To see this we heated a soft drink can with water in it. The water turned into a hot gas(vapor). The can was put into a tub of cold water and it imploded. This happened because the water vapour inside the can contracted, due to the sudden change from hot to cold.
Diffusion(hot vs cold water)
The last experiment we did was aiming to see diffusion. Diffusion’s when particles move from high to low concentration(particles are closer together, then spread out). We put a purple crystal(potassium permanganate) into two different petri dishes. One petridish had hot water, the other cold. The permanganate dyed the water. The hot water was turning purple faster. We concluded that this happened because the purple particles diffused faster with heat.
My favourite experiment was the convection one because it looked pretty cool when the purple was moving in circles. Here is the writeup I did about it:
|
|
Title – Your title should tell readers about your experiment |
Convection |
What is Convection? |
Find or draw a picture that shows the process of convection and put it here:
Convection happens w hen you heat up a gas or liquid. Then the hotter particles rise up because they are less dense and the cooler particles fall down. |
Aim |
The aim of this experiment was to see convection happen. |
Hypothesis – What do you expect might happen? |
During this experiment, I predicted that the potassium permanganate crystal would move around in a circle(like in the diagram). |
Equipment – What equipment did we use? |
The equipment I used was:
- Water
- Potassium permanganate
- Straw
- Beaker
- Tweezers
- 1 Ice cube
- Bunsen burner
- Tripod
- lighter
- Heatproof mat
|
Method – What steps did you follow to complete this experiment? |
The step-by-step method for my experiment is as follows:
- Put a heatproof mat on a flat surface
- Connect the bunsen burner to the gas valve the place it on the mat, close the airhole
- Place the tripod over the bunsen burner and put a gauze mat on the tripod
- Fill a 200ml beaker with 150ml of water and put one ice cube in it
- Put the beaker on the tripod
- Put a straw in the beaker
- With tweezers, put a potassium permanganate crystal through the straw
- Remove straw
- Hold lighter above bunsen burner then turn on gas valve, open air hole
- Observe the permanganate
|
Results
With your group, make observations about how the water circulates when heated and record them here |
During the experiment I observed that:
- The potassium permanganate left a purple trail in the water
- The trail went in a circle(went up then down)
- The water slowly became purple
|
Discussion
Using the word list below, explain how heating the water caused the water to move in the way it did:
- Colder
- Particles
- Convection
- Warmer
- Less dense
- More dense
List two more ways you could make the results of your experiment more accurate. |
When the water nearest the bunsen flame is heated, the particles become warmer(less dense) so they rise. After moving away from the heat source, the particles become colder(more dense) then sink down. The particles move in a circle, this is called a convection current.
I could make my experiment better by:
- Video recording the convection process
|
Conclusion
Finish this sentence to conclude your science report. |
My results supported my hypothesis because my results showed that the potassium permanganate did move in a circle. BUT, I did not imagine that it would leave a trail and make the water purple. |
